3/16’ Raychem Dr-25 (Yellow Label) Heat Shrink Tubing
3/16’ Raychem Dr-25 (Yellow Label) Heat Shrink Tubing
Part #: DR-25-3/16-0-SP

3/16" Raychem DR-25 (Yellow Label) Heat Shrink Tubing (per foot)

TE Connectivity / Raychem
In stock - 88 Available for Immediate Shipment
$1.69

Secure checkout

Friendly support

Hassle-free returns

3/16" Raychem DR-25 (Yellow Label) Heat Shrink Tubing.  This is the USA market 'yellow label' DR-25.  Priced and sold per foot.

Specifications from the manufacturer Raychem (TE Connectivity)

    • Specially formulated for optimum high-temperature fluid resistance, and long term heat resistance. Resistant to aviation and diesel fuels, hydraulic fluids and lubricating oils. Particularly suitable as a jacketing material for military ground vehicle cables and harnesses. It is also well suited for the demands of motorsport cable harnesses.
    • Operating temperature range: 75¸C to 150¸C (-103¸F to 302¸F)
    • Shrink ratio: 2:1
    • Minimum shrink temperature: 150¸C (302¸F)
    • Minimum full recovery temperature: 175¸C (347¸F)

    Factory spool size is 150 ft.
